Blade Binding Machine
Key words:
Category:
Details
Technical Data
|
Model |
SEBB-80 |
|
Raw Material |
Aluminum 5052H19/ Tin Stee |
|
Materia Thickness |
0.2 mm |
|
Mother Rol Core Diameter |
152 mm |
|
Max Mother Roll Out Diameter |
800 mm |
|
Mother Roll Available Width |
100-455 mm |
|
Length of Feeding |
5-10 mm |
|
Speed |
20-50 pcs/min |
|
Paper Box Material |
250-300 gsm Ivory Board/ 400 gsm White Board |
|
Paper Box Size |
L300 mm-410 mm/ W 235 mm-330 mm |
|
Installed Power |
4.0KW |
|
Power Supply |
380V, 50Hz, 3ph+N+E (Remark3) |
|
Air Pressure |
0.5-0.8 Mpa, 500 L/hour |
|
Dimensions L x Wx H |
3000x1800x1100 mm |
| Net Weight |
1500 kg |
Description
The Semi Auto Box Blade Binding Machine model SEBB-80 which has been specifically studied for binding the Blade into the carton box of Household foil/ Cling Film. It continue Feeding Material to Hydraulic Saw Cutting Mould and together Binding with Paper box. Manual put paper box sheet into the mould, after binding take out and put another paper box sheet. Press by Foot Switch.
The Production Process
1.Loading Mother Roll of Saw Blade into Decoiler.
2.Feed material to Saw Blade Cutting Mould.
3.Setup feeding length in touch screen.
4.Adjust the hand put paper box position and fixed.
5.Manual put paper box to the position and push Foot switch to Bind blade with paper.
6.Take out paper sheet after binding and put another new paper sheet.
